Daikin Ductable AC

Daikin Ductable AC Specification

Compressor
Hermetically Sealed Scroll Type

Dimension (L*W*H)
1460 x 955 x 390 mm

Condition
New

Power Mode
Auto

Place of Origin
India

Type Of Compressor
Scroll

Air Flow Capacity
2100 CFM

Mounting
Ceiling Concealed

Indoor Fan Input
300 W

Filtration Grade
Washable Pre-Filter

Outdoor Fan Input
370 W

Cooling Capacity
66000 BTU/hr

Power Consumption
7100 W

Temperature Control
Digital Thermostat

Running Current
12.5 A

Sensible control
Yes

Refrigerant
R410A

Power Supply
380-415V/3Ph/50Hz

Type
Ductable AC

Cooling/Heating
Cooling Only

Capacity
5.5 Ton

Power Source
Electric

Voltage
380-415V / 3 phase / 50 Hz

Color
White

Weight (kg)
140 kg

Working Temperature
16C - 52C

Fan Speed
Multi Speed

Noise Level
52 dB

Energy Efficiency Rating
3 Star

Remote Operated
Yes

Display Type
LCD Display

Packaging Type
Wooden Crate

Application Area
Commercial/Industrial

Outdoor Unit Model
RZR60QV16

Indoor Unit Model
FDMRN60QV16

Condenser Coil Material
Copper

Static Pressure
100 Pa

Anti-corrosion Treatment
Yes

Installation Service Provided
Optional

Minimum Air Throw Distance
18 meters

Dehumidification
Yes

Evaporator Coil Material
Copper

Moisture Removal
4.2 L/hr

Control System
Microprocessor Based

Phase
Three Phase

Panel Type
Powder Coated Galvanized Steel

Frequency
50 Hz

Pipe Connection Size
Suction 7/8", Liquid 3/8"

About Daikin Ductable AC

A ducted air conditioner, also known as central air conditioning, is a system that uses a network of ducts to circulate conditioned air throughout a building. The system has an indoor and outdoor unit, and the indoor unit is usually installed in the roof space.

Here are some features of ducted air conditioning:

Efficiency: Ducted air conditioning is an efficient way to cool a home.
Discreet: The system is practically invisible because only the air supply grilles are visible in the ceiling or wall.
Programmable grilles: The air flow in each room is regulated by strategically placed programmable grilles.
Airflow design: Some ducted air conditioners have an airflow design that improves energy efficiency.
Protection circuits: Some ducted air conditioners have protection circuits that protect the compressor from damage caused by voltage fluctuations, phase loss, high or low pressure, and reverse phase

Superior Cooling for Commercial Spaces

Engineered for expansive commercial and industrial environments, this ductable AC offers reliable cooling in harsh conditions, functioning smoothly between 16C and 52C. Its strong air throw of 18 meters and static pressure of 100 Pa ensure even cooling throughout large areas while maintaining low noise levels for minimal workplace disruption.

Robust Construction & Advanced Features

Built with powder-coated galvanized steel and copper coils, the Daikin Ductable AC is designed for long-lasting performance and resistance to corrosion. The indoor unit features a multistage fan, digital thermostat, and LCD display for precise control and easy monitoring. Its microprocessor-based system ensures consistent efficiency and easy integration with building management systems.

Flexible Installation & Maintenance

The ceiling concealed mounting and optional installation service provide versatility for various layout requirements. A washable pre-filter extends maintenance intervals, and the system's packaged in a durable wooden crate for secure delivery. Remote operation and accessible controls enhance convenience for users and maintenance personnel.

FAQ's of Daikin Ductable AC:

Q: How is the Daikin Ductable AC installed, and is installation service provided?

A: This unit is designed for ceiling concealed mounting, allowing discrete installation in commercial or industrial settings. Daikin offers optional professional installation service to ensure proper setup and system optimization.

Q: What are the advantages of copper coils in the evaporator and condenser?

A: Copper coils provide enhanced heat exchange efficiency, greater durability, and improved corrosion resistance. This leads to better cooling performance, reduced maintenance, and extended lifespan for your air conditioning system.

Q: When should the washable pre-filter be cleaned or replaced?

A: The washable pre-filter should be checked and cleaned at regular intervals, typically every 2-4 weeks, depending on environmental conditions and usage. Regular maintenance ensures efficient filtration and optimum airflow.

Q: Where is this ductable AC most effectively used?

A: This model is intended for commercial or industrial applications, such as offices, factories, malls, or warehouses, where large, open spaces require consistent cooling. Its high air flow capacity and robust construction suit demanding environments.

Q: What control and display options does the Daikin Ductable AC offer?

A: The system features a microprocessor-based control with an LCD display for monitoring and adjustments. It also includes a digital thermostat for precise temperature control and supports remote operation for user convenience.

Q: How does the AC handle humidity and moisture removal?

A: Equipped with a dehumidification function, the Daikin Ductable AC actively removes up to 4.2 liters of moisture per hour from the air, ensuring comfort and protecting sensitive equipment or product inventory from excess humidity.
