Package AC

Package AC Specification

Dimension (L*W*H)
2200 x 1050 x 900 mm

Mounting
Floor Standing

Power Consumption
9.5 kW

Filtration Grade
Pre and Fine Filter

Compressor
Scroll

Cooling Capacity
120,000 BTU/hr

Running Current
16 Amp

Condition
New

Refrigerant
R407C

Air Flow Capacity
2500 CFM

Power Supply
3 Phase, 50 Hz

Outdoor Fan Input
0.75 kW

Place of Origin
India

Sensible control
Yes

Temperature Control
Digital Thermostat

Indoor Fan Input
0.60 kW

Power Mode
Automatic

Type Of Compressor
Hermetically Sealed

Type
Packaged AC Unit

Cooling/Heating
Cooling Only

Capacity
10 Ton

Power Source
Electric

Voltage
380-415 V

Color
White & Grey

Weight (kg)
185 kg

Working Temperature
18C to 50C

Fan Speed
Multi

Noise Level
62 dB

Energy Efficiency Rating
3 Star

Remote Operated
Yes

About Package AC

A packaged air conditioner is a self-contained unit that provides heating and cooling for a space. Its made up of all the essential components, such as the compressor, coils, air filter, and air handling unit, in a single outdoor unit. The unit is then connected to ductwork that distributes conditioned air to different parts of the space.

Here are some features of packaged air conditioners:

Assembly: Packaged air conditioners are assembled at the factory and can be easily transported to the site.
Location: The unit is placed on the roof or to the side of the property.
Ductwork: The unit is connected to ductwork through a single hole in the outside wall.
Heating: Some packaged air conditioners can also provide limited heating with an electrical strip.
Humidity control: Packaged air conditioners can offer better humidity control.
Space efficiency: Packaged air conditioners are space efficient.
Cost: Packaged air conditioners are cheaper due to saving on installation costs.
Lifespan: The lifespan and effectiveness of a packaged air conditioner can be reduced due to exposure to the elements.
Energy efficiency: Packaged air conditioners usually have an 8-10 SEER rating.
Packaged air conditioners are ideal for conditioning in places such as restaurants, homes, telephone exchanges, and small halls.

Efficient Cooling for Demanding Applications

Designed for commercial and industrial settings, this packaged AC unit delivers consistent performance with 120,000 BTU/hr cooling capacity. Its copper coils, energy-efficient compressor, and smart digital controls ensure longevity and precise temperature maintenance, even in extreme temperatures. Floor-standing and easy to install, it provides dependable cooling exactly where needed.

Advanced Controls and Easy Operation

The unit is equipped with a robust microprocessor-based control panel that allows users to manage temperature and operating modes with ease. The digital thermostat and multi-speed centrifugal fan ensure even air distribution, while features like LED status indicators and automatic drain simplify operation and maintenance.

Durable and Reliable Construction

Built with all-copper coils and a hermetically sealed scroll compressor, the system withstands harsh usage and delivers stable cooling. Its heavy-duty build, advanced filtration, and overload protection ensure efficiency and safety for industrial or commercial spaces.

FAQs of Package AC:

Q: How is the Package AC Unit installed and what is included in the installation kit?

A: The unit is designed for floor-standing installation. The included installation kit provides all necessary components for a standard setup, ensuring a secure and efficient connection to your facilitys power and ductwork systems.

Q: What are the primary benefits of copper evaporator and condenser coils in this AC unit?

A: Copper coils offer excellent thermal conductivity, faster cooling, and a longer lifespan compared to other materials. They also enhance the units energy efficiency and make maintenance simpler.

Q: Where is the Package AC Unit best suited for use?

A: This unit is ideal for commercial and industrial spaces requiring substantial coolingsuch as factories, server rooms, large offices, and workshopsthanks to its 10-ton capacity and robust airflow.

Q: What kind of protection features does the unit offer?

A: It is equipped with overload and phase protection to safeguard the motor and electrical components, minimizing the risk of damage and downtime during voltage fluctuations or unexpected power surges.

Q: How does the microprocessor-based control panel benefit daily operation?

A: The control panel allows users to customize settings, monitor system status via LED indicators, and maintain precise temperature control with the digital thermostat. This streamlines operation and troubleshooting.

Q: What is the process for maintenance and is the auto drain feature helpful?

A: Maintenance is straightforward, with pre and fine filters for air purification and an auto-drain system that prevents water buildup, reducing manual intervention and making regular upkeep convenient.

Q: Can the unit be upgraded with additional features like WiFi control or fresh air intake?

A: Yes, optional features such as WiFi control for remote monitoring and fresh air intake for improved ventilation can be added, enhancing system flexibility and user convenience.
